The Rolling Marbles

Event Year: 2021
Event Location: Virtual
Competition: Energy Transfer Machine
Division: 9-12
School: Dreyfoos School of the Arts/The Benjamin School
Team Size: 2

Hello, our names are Ellie B. and Tyler K. We are freshmen in high school at the Dreyfoos School of the Arts and The Benjamin School, respectively. Our Energy Transfer Machine took us over three months to complete. We were inspired by our last machine, which had several flaws. In this machine, we wanted to both correct those flaws and improve our design capabilities. Our adult helper was Susan Bickel. Below is our video explaining the steps of our Energy Transfer Machine and our actual run.

Our Steps:

  1. Stomp rocket compresses air forcing the rocket to launch.
  2. The rocket launches, pulling a string.
  3. The pulled string in turn pulls a piece of cardboard out of the foam insulation tubing.
  4. Gravity pulls the marbles down to the turbine.
  5. The marbles hit the turbine, forcing the blades to spin.
  6. The blades of the turbine spin a wooden dowel.
  7. The wooden dowel has a weighted plastic cup attached which lowers as the dowel spins.
  8. Attached to the plastic cup is a strip of paper that is pulled down with the cup.
  9. The end of the paper is embedded between two wires attached to a battery-powered mower. When the cup reaches the bottom, the paper is pulled out, allowing the wires to connect and complete the circuit.
  10. When the circuit completes, a fan blade spins.
  11. The fan blade knocks a balanced marble.
  12. Gravity pulls the marble down a foam tube.
  13. The marble falls down a hole and knocks into wooden blocks which domino down.
  14. The last block hits a small, green car.
  15. Gravity pulls the car down a track.
  16. The car hits a lid.
  17. The lid moves.
  18. The movement causes a metal ball bearing to move down a tube.
  19. The ball-bearing zig-zags down a track and drops into a plastic cup.
  20. The plastic cup falls.
  21. The string attached to the plastic cup pulls a foam piece out of another tube releasing a marble.
  22. Gravity pulls the marble through a tube which includes a loop de loop.
  23. The marble knocks over a graduated cylinder capped by a balloon.
  24. The graduated cylinder contains a citric acid solution and the balloon contains baking soda.
  25. The balloon blows up.

Our Battery:

We used a battery-powered motor to spin a fan. The fan then knocked a marble. The circuit was prevented from completing by a strip of paper, which was pulled away by a cup lowered by our turbine, allowing the circuit to complete.

Our Chemical Reaction:

We filled a balloon with baking soda and attached it to a graduated cylinder filled with a citric acid solution. When our graduated cylinder was knocked over by a marble at the end, the balloon inflated, our end goal.

Our Process and Problems:

In this image, we are working on the problem of aligning our stomp rocket, marble corridor, and turbine. It was difficult to align and time everything.
This photograph shows us working on the battery-powered fan. It was very difficult to get this part right and working consistently.
This images shows us working on the alignment of the dominoes around the curve. It was difficult to get the spacing right.
In this photo, we are calibrating the ratios of our chemical reaction, which contains baking soda and citric acid.

Thank you for considering our project, we spent a lot of time on it, and we hope you enjoy it!

THE END
